IKO Linear Way E LWESC30 (C-Lube)
The IKO LWESC30 is a compact, flange-type linear guide block from the Linear Way E (LWE) series, designed for general-purpose linear motion applications. It features two rows of steel balls in 4-point contact with raceways, delivering stable accuracy and rigidity under fluctuating or complex loads. The C-Lube variant offers maintenance-free lubrication for extended service life.
Overview
The IKO LWESC30 is a compact, flange-type linear guide block from the Linear Way E (LWE) series, designed for general-purpose linear motion applications. It features two rows of steel balls in 4-point contact with raceways, delivering stable accuracy and rigidity under fluctuating or complex loads. The C-Lube variant offers maintenance-free lubrication for extended service life.
Basic Specifications (Official Data)
| Parameter | Value |
|---|---|
| Model | LWESC30 (C-Lube) |
| Type | Compact flange block, top-mount |
| Mass (Slide Unit) | 0.42 kg |
| Mass (Track Rail) | 4.25 kg/m |
| Overall Height (H) | 42 mm |
| Mounting Height (H1) | 10 mm |
| Block Width (W2) | 60 mm |
| Rail Width (W) | 30 mm |
| Block Length (L4) | 80 mm |
| Basic Dynamic Load Rating (C) | 18.8 kN |
| Basic Static Load Rating (C₀) | 22.5 kN |
| Static Moment Rating (Mₓ) | 0.58 kN·m |
| Static Moment Rating (Mᵧ) | 0.58 kN·m |
| Static Moment Rating (M_z) | 1.18 kN·m |
| Material | Bearing steel (stainless steel optional) |
| Precision Grades | C (Normal), H (High), P (Precision) |
| Lubrication | C-Lube (built-in, maintenance-free) |
Key Features
Compact & Flange Design: Flange-type block for easy top mounting; saves space in tight installations.
4-Point Contact Ball Design: Two rows of steel balls ensure high rigidity and accuracy under radial, axial, or combined loads.
C-Lube Self-Lubrication: Integrated lubrication unit eliminates the need for regular grease replenishment, reducing maintenance and environmental impact.
Interchangeable: Blocks and rails are dimensionally interchangeable within the LWE series, enabling flexible assembly and replacement.
Low Noise: Resin ball separators prevent metal-to-metal contact, ensuring smooth, quiet operation.
Corrosion Resistance: Stainless steel options available for cleanroom, medical, or semiconductor applications.
Applications
General automation machinery
Semiconductor & LCD manufacturing equipment
Medical devices
Packaging machinery
Precision inspection equipment
